- Sensor Size(Inch): 1/3
- Model Number: V70H-F
- Samrt Home Interface: No
- Communication Interface: Wired
- Access Control: None
- Display Screen Size(inch): 7
- Power: AC 110V - 240V
- Answering Mode: Hands-free
- IP Camera Interface: No
- Technology: Digital
- Zone Input: None
- Type: Intercom System
- Camera Sensor type: CMOS
- Viewing Angle (°): 90
- Doorbell: Yes
- Size: 228 x 114 x 20mm
- Installation: Wall Mounting
- Connection Method: Wired
- Display Screen Type: Color
- Waterproof: Yes
- Kit Configuration: One to Four Video Doorphone
- Brand Name: DIYSECUR
- Material: Plastic
- Camera: Colours
- Power: AC 110V - 240V
- Resolution: 700TVLine
NEW Arrival 4-Wire 7" Video Door Phone Intercom System
1 x Outdoor Unit & 4 x Indoor Monitors

Video door phone is a system that enables you to receive "calls" from your front door or some other door on the outside of your building, which enables you to actually see who is at the outside station and talk to them. It will add security and peace of mind to your house.
The item you are watching now is our new arrival video door phone system. It has nice appearance and excellent performance. About the outdoor unit, a 700tvl camera lets you see who is at the door clearly, built-in led lights enhance the night view, the aluminum alloy outer casing and rainproof cover provide a good protection for it. About indoor monitor, a 7inch LCD color screen gives you great view, white acrylic panel makes it look more elegant . Besides, it is a 4-wire system, the installation is not difficult, both of the outdoor unit and indoor unit have plug-and-play connector. It is a great system for home intercom and security.
It supports Handsfree Dual-way Intercom, Indoor Monitoring, Indoor Unlocking, Night Vision and Mute Mode. It contains 1 outdoor unit and 4 indoor unit. It supports Max 2 outdoor units and 6 indoor units, if you need more cameras and monitors, please feel free to contact us. (For 2 outdoor unit kit, you need a mutil door controller; for 5 or 6 indoor units kit, you need a mutil monitor amplifer.)
The outdoor unit has Durable and Vandal-proof outer casing and rainproof cover for better protection, which is suitable for outside mounting, the black gray color makes it more compitable with your wall. The indoor unit has good shape, white color and PMMA makes it look more elegant. Stable microphone and speaker provide better Video&Audio performance.
When a visitor ring the bell, the monitor will be activated and show the image outside, then you can see and hear outside. Press the answer button, then you can talk to outside, press the answer button again to turn it off. If you do not press the button after conversation is finished. If no one answer the call, the monitor will turn off automatically after 60s. It supports monitoring feature, press the monitoring button, you can see and hear outside situation.
The outdoor unit embeds in 6 led lights, the lights will turn on once camera is activated (someone presses the call button or presses the monitor button). This feature allows you can still see color image (Not Black&White) at night. It is a brilliant design.
This door phone can work with 12V electrical lock, so you can connect an electrical lock to this system. With this function, you don\'t need go to the door to open door for your guest, you just need to press unlock button on monitor. This will bring great convenience for you and your family members.
(Please note the electrical lock at below photo is not included, if you need it, please contact us)
If you use NO lock, you can connect it to outdoor unit directly without extra power supply. But for an NC strike lock or magnetic lock, you need to add an extra 12V power supply module. We can provide such power supply module, electrical lock, remote controller and exit button, if you need these kits, please contact us for quotation.
More Details:
This door phone system can be widely used in Villa, office, private house, and other place needs intercom. It is not only a intercom system, but also a home security system.
We provide more options for the outdoor and indoor unit. There are several models that you can choose as you wish, please contact us for quotation with the model.
Specifications:
Outdoor Camera | ||
Model No. | F | |
Night Vision | LED Light, visible within 5 meters | |
Vision Angle | 90 Wide Angle | |
Resolution | 700 TV Line | |
Plus Control | Automatically | |
Power Consumption | Standby: 0.1W; Working: 4W | |
Working temperature | -10°c~+55°c | |
Installation | Wall mounted | |
Material | Aluminum alloy and ABS | |
Size | 180(L)*79(W)*50(H)mm | |
Net Weight | 460g | |
Indoor Monitor | ||
Model No. | V70H | |
Screen | 7\'\' wide angle TFT LCD, 16:9 Display | |
Resolution | 800*RGB*480 | |
Power input | AC100V-240V 50Hz-60Hz | |
Delay Calling time | 120s 10% | |
Delay Monitoring time | 40s 10% | |
Valid Distance | 100M (4x0.65 mm2) | |
Power Consumption | Standby: 0.5W; Working: 8W | |
Adapter Input | AC100~ 240V, 50/60Hz | |
Adapter Output | DC 15V | |
Working Temperature | -40°c~+70°c | |
Standby Temperature | -20°c~+60°c | |
Installation | Wall mounted/lift on desk | |
Size | 228(L)*114(W)*20(H)mm | |
Materail | ABS | |
Net Weight | 390g |
What\'s in:
- Unit Type: piece
- Package Weight: 2.0kg (4.41lb.)
- Package Size: 30cm x 20cm x 20cm (11.81in x 7.87in x 7.87in)
- Unit Type: piece
- Package Weight: 2.0kg (4.41lb.)
- Package Size: 30cm x 20cm x 20cm (11.81in x 7.87in x 7.87in)
