Item specifics
  • Brand Name: chuangkesafe
  • Connection Method: Wired
  • Camera Sensor type: CMOS
  • Answering Mode: Hands-free
  • Display Screen Size(inch): 7
  • Kit Configuration: One to One video doorphone
  • Viewing Angle (°): 90
  • Type: Intercom System
  • Display Screen Type: Color
  • Zone Input: None
  • Communication Interface: Wired
  • Installation: Wall Mounting
  • Technology: Digital
  • Samrt Home Interface: Yes
  • Waterproof: Yes
  • Access Control: None
  • IP Camera Interface: No
  • Model Number: XSL-V70A-M3
  • Power: 220v
  • Resolution: 420TVLine
  • Sensor Size(Inch): 1/3
  • Power: AC110V-240V 50HZ-60HZ
  • Material: Aluminium Alloy
  • Doorbell: Yes
  • Size: 350x150x100mm
  • Camera: color
  • Camera: 1/3 CMOS 700 line
  • Product Name: Video Door Phone
  • Function: Intercom,Monitor,Unlock
  • Type: Security and Protection System
  • Screen: 7 Inch TFT-LCD 800*480Pixel
  • Color: White
  • Case: ABS Plastics , Acrylic lenses,Aluminium alloy
  • Outdoor camera: Waterproof & Night Vision
  • Application: Apartment,Villa,Home Security
Product Description





aeProduct.getSubject()

Product Description

Feature:

  • With micro-processing technology, auto-remote control, excellent performance and high reliability
  • The TFT 7 inch digital color LCD for monitor
  • Clear night viewing
  • 24 hours monitoring, calling, speaking and unlocking remote controlling etc
  • Additional monitor available up to 6(optional) and 4 outdoor cameras at most
  • TFT color screen with low power consumption, no radiation and high definition
  • Hands-free intercommunication
  • Brightness, chroma and volume adjustable
  • 36-chord melody rings for option
  • Cabling: 4-core connection cable
  • Do not disturb mode
Specification
Indoor Unit Parameters
Outdoor Unit Parameters
Model XSL-V70A Model XSL-M3
Power Supply Input: AC 100-240V
Output: DC 15V 1500mA 		Power Standby: 0W Working:2W
Power Standby: 1W Working:10W Camera Resolution 1/3 CMOS 700 line
Super backlight compensation
Screen 7"Colour TFT Liquid Crystal Display Night Version WLED 3m
Wiring 4 PIN Line RVV5 Case Aluminium alloy
Video Signal 1 VP-P Illumination 0.1Lux
Timing Monitoring: 60 seconds Intercom: 60 seconds Viewing Angle 92 Degrees
Working Temperature 20-+60 Working Temperature 20+60
Ringtone 36 chord Installation Surface mounting
Weight 0.46KG Weight 0.26kg
Dimension 240x150x26 mm Dimension 55x128x40 mm
Detail of Monitor

aeProduct.getSubject()aeProduct.getSubject()

aeProduct.getSubject()
aeProduct.getSubject()


Detail Of Camera

aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()aeProduct.getSubject()

Installation

aeProduct.getSubject()aeProduct.getSubject()

Product Fittings

aeProduct.getSubject() aeProduct.getSubject()

aeProduct.getSubject()

Packaging Details
  • Unit Type: Set
  • Package Weight: 0.8kg (1.76lb.)
  • Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
